Advantech ADAM

I/O & Integration Modules

Advantech ADAM-4000 series distributed RS-485 I/O modules, read over Modbus RTU or the ADAM ASCII protocol. Analog input modules accept voltage, current (4-20 mA / ±20 mA), thermocouple, and RTD signals; analog output modules drive current/voltage loops. Each module's channels map to the generic Analog Input parameter, and the input range for each channel is set in the driver.

Schedule a call Build a Configuration

Measures

What the Advantech ADAM Measures

1 parameter, linked to its page on sensors, units, and standards.

Analog Input (generic)Ch0, Ch1, Ch2, Ch3, Ch4, Ch5, Ch6, Ch7

Connects via Thiamis

Wired interfaceRS-485ASCIImulti-drop

Models

Advantech ADAM Models

12 models, each with what it measures and the ranges its datasheet gives.

Model	Description	Measures & specs
ADAM-4011	1-channel thermocouple / mV input module with 2 digital inputs and 1 alarm output. Reads J, K, T, E, R, S, and B thermocouples plus millivolt/volt signals over RS-485, with cold-junction compensation.	Channels: 1Signals: Thermocouple J/K/T/E/R/S/B, ±15 mV, ±50 mV, ±100 mV, ±500 mV, ±1 V, ±2.5 V Analog Input (generic)Ch0, Ch1, Ch2, Ch3, Ch4, Ch5, Ch6, Ch7
ADAM-4012	1-channel analog input module with 2 digital inputs and 1 alarm output. Per-channel voltage or current range selected in software over RS-485.	Channels: 1Signals: 4-20 mA, ±20 mA, ±10 V, ±5 V, ±1 V, ±500 mV, ±150 mV Analog Input (generic)Ch0, Ch1, Ch2, Ch3, Ch4, Ch5, Ch6, Ch7
ADAM-4013	1-channel RTD input module. Reads Pt-100 / Pt-1000, Balco-500, and Ni RTDs (2-, 3-, or 4-wire) over RS-485.	Channels: 1Signals: RTD Pt-100, RTD Pt-1000, RTD Balco-500, RTD Ni Analog Input (generic)Ch0, Ch1, Ch2, Ch3, Ch4, Ch5, Ch6, Ch7
ADAM-4015	6-channel RTD input module. Per-channel Pt, Ni, and Balco RTD input (2- or 3-wire) over RS-485.	Channels: 6Signals: RTD Pt-100, RTD Pt-1000, RTD Ni, RTD Balco-500 Analog Input (generic)Ch0, Ch1, Ch2, Ch3, Ch4, Ch5, Ch6, Ch7
ADAM-4017	8-channel analog input module (6 differential + 2 single-ended). Per-channel voltage and current ranges over RS-485.	Channels: 8Signals: 4-20 mA, ±20 mA, ±10 V, ±5 V, ±1 V, ±500 mV, ±150 mV Analog Input (generic)Ch0, Ch1, Ch2, Ch3, Ch4, Ch5, Ch6, Ch7
ADAM-4017+	8-channel differential analog input module. Same voltage/current ranges as the ADAM-4017 with faster sampling and per-channel enable.	Channels: 8Signals: 4-20 mA, ±20 mA, ±10 V, ±5 V, ±1 V, ±500 mV, ±150 mV Analog Input (generic)Ch0, Ch1, Ch2, Ch3, Ch4, Ch5, Ch6, Ch7
ADAM-4018	8-channel thermocouple / mV input module (6 differential + 2 single-ended). Reads J, K, T, E, R, S, and B thermocouples over RS-485.	Channels: 8Signals: Thermocouple J/K/T/E/R/S/B, ±15 mV, ±50 mV, ±100 mV, ±500 mV, ±1 V, ±2.5 V, 4-20 mA Analog Input (generic)Ch0, Ch1, Ch2, Ch3, Ch4, Ch5, Ch6, Ch7
ADAM-4018+	8-channel thermocouple input module with per-channel open-circuit (burn-out) detection.	Channels: 8Signals: Thermocouple J/K/T/E/R/S/B, ±15 mV … ±2.5 V, 4-20 mA Analog Input (generic)Ch0, Ch1, Ch2, Ch3, Ch4, Ch5, Ch6, Ch7
ADAM-4019+	8-channel universal analog input module. Each channel is independently configurable for voltage, current, thermocouple, or RTD input.	Channels: 8Signals: 4-20 mA, ±20 mA, ±10 V, ±5 V, ±1 V, ±500 mV, ±150 mV, Thermocouple J/K/T/E/R/S/B, RTD Pt-100 Analog Input (generic)Ch0, Ch1, Ch2, Ch3, Ch4, Ch5, Ch6, Ch7
ADAM-4021	1-channel analog output module. Programmable current or voltage output to drive valves, actuators, and setpoint controllers over RS-485.	Channels: 1Signals: 4-20 mA, 0-20 mA, 0-10 V, 0-5 V Analog Input (generic)Ch0, Ch1, Ch2, Ch3, Ch4, Ch5, Ch6, Ch7
ADAM-4022T	Analog output / setpoint module. Channel count and output ranges not yet verified against a current Advantech datasheet.	Analog Input (generic)Ch0, Ch1, Ch2, Ch3, Ch4, Ch5, Ch6, Ch7
ADAM-4024	4-channel analog output module with 4 digital inputs. Per-channel current or voltage output for process control and actuator drive.	Channels: 4Signals: 4-20 mA, 0-20 mA, ±10 V, 0-10 V Analog Input (generic)Ch0, Ch1, Ch2, Ch3, Ch4, Ch5, Ch6, Ch7

On the platform

What the Advantech ADAM Gets From Aethair

Connected through Thiamis, its readings arrive in the same Environet account as Aethair's own monitors.

Live data and alerts

Environet shows the instrument live and alerts the people you choose by email, SMS, and webhook, at the thresholds you set. Noesis sets up a dashboard, a report, or an alert from a plain-text request.

Compliance reports

Aethair Reports produces scheduled or on-demand reports from the instrument's readings, as a PDF or secure link. Templates cover Aethair Blue, WELL v2, cabin air (ISO 23875), and the CMS-2567 healthcare codebook (ASHRAE 170), or you can report against custom limits such as OSHA PELs, NAAQS, EPA guidance, or your own program limits.

Dashboards and the app

Environet dashboards and the Aethair App show the instrument's readings just like any Aethair device. The occupant-facing Aethair Dashboards status display is built around Aethair IAQ and Aethair PRO.

Sources: www.advantech.com
