Every Sensor the Platform Reads

Aethair CO electrochemical

Gas 0d01

• CO 0-1000 ppm res. 1 ppm

Carbon monoxide cartridge. An amperometric electrochemical CO cell with a solid, non-aqueous electrolyte (the long-life, low-power sensing element used in residential and commercial CO alarms), for combustion safety, garages, and workplace air monitoring.

Aethair CO₂ dual NDIR

Gas 0d02

• CO₂ 0-5000 ppm res. 1 ppm

Carbon dioxide cartridge. Dual-thermopile NDIR (non-dispersive infrared) sensing measures CO₂ with no chemical consumables, for demand-controlled ventilation, HVAC, and indoor air quality.

Aethair VOC ppm PID

Gas 0d03

• VOC (Total) 0-4000 ppm res. 0.1 ppm

Total VOC cartridge (ppm range). A 10.6 eV photoionization detector (PID) ionizes volatile organic compounds for direct ppm readings across a wide range. Used for industrial hygiene, leak detection, and fenceline monitoring of solvent, fuel, and off-gassing vapors.

Aethair CO₂ self-calibrating NDIR

Gas 0d04

• CO₂ 0-5000 ppm res. 1 ppm

Carbon dioxide cartridge. NDIR (non-dispersive infrared) sensing with automatic background self-calibration for maintenance-free CO₂ measurement in demand-controlled ventilation and indoor air quality.

Aethair NO₂

Gas 0d05

• NO₂ 0-20 ppm res. 20 ppb

Nitrogen dioxide cartridge. Four-electrode electrochemical sensing resolves NO₂ down to parts-per-billion, for roadside traffic, combustion, and ambient air-quality networks.

Aethair Diff. Pressure

Expansion 0d08

• Differential Pressure 0-10000 Pa

Differential-pressure cartridge for the Aethair PRO expansion socket, for room-to-room pressure monitoring in cleanrooms and containment. A gauge sensor reads 0–10 kPa, with the higher-pressure side connected to its port.

Aethair MultiSense

MultiSense 0d09

• NO₂ 0-20 ppm res. 20 ppb
• CH₂O 0-10 ppm res. 10 ppb
• SO₂ 0-20 ppm res. 10 ppb

Multi-gas sensor cartridge. Simultaneous electrochemical detection of sulfur dioxide, nitrogen dioxide, and formaldehyde at parts-per-billion resolution, for ambient and indoor air-quality monitoring.

Aethair CH₄

Gas 0d0a

• CH₄ 0-100 %LEL res. 1 %LEL

Methane cartridge. Molecular Property Spectrometer (MPS) MEMS sensing, poison-immune and factory-calibrated for life, for combustible-gas monitoring in %LEL.

Aethair O₂

Gas 0d11

• O₂ 0-30 % res. 0.1 %

Oxygen cartridge. A self-powered galvanic electrochemical cell with instant-on response measures O₂ from 0 to 30%, for oxygen depletion and enrichment monitoring.

Aethair VOC ppb PID

Gas 0d13

• VOC (Total) 0-40 ppm res. 1 ppb

Total VOC cartridge (ppb range). A high-sensitivity 10.6 eV photoionization detector (PID) resolves volatile organic compounds to single-digit ppb, for low-level VOC monitoring in indoor air quality and fugitive-emissions surveillance.

Aethair NO

Gas 0d15

• NO 0-20 ppm res. 15 ppb

Nitric oxide cartridge. Biased four-electrode electrochemical sensing resolves NO to parts-per-billion, for combustion, NOₓ, and ambient air-quality monitoring.

Aethair MultiGas+

Gas 0d16

• CH₄ 0-10000 ppm res. 10 ppm
• CO 0-1000 ppm res. 1 ppm
• VOC (Total) 0-100 ppm res. 1 ppm

Combination cartridge. Metal-oxide semiconductor (MOS) sensing tracks carbon monoxide, methane, and total VOC from a compact element, for combustible-gas safety and indoor air-quality monitoring. A MOS element responds to all three gases and to humidity, so its readings are indicative trends rather than selective measurements.

Aethair VOC ppb PID, wide range

Gas 0d25

• VOC (Total) 0-4000 ppm res. 1 ppb

Total VOC cartridge (ppb range). Photoionization detection (PID) resolves volatile organic compounds to parts-per-billion, for low-level VOC monitoring in indoor air and process environments.

Aethair CO ppb, four-electrode

Gas 0d35

• CO 0-1000 ppm res. 4 ppb

Carbon monoxide cartridge. Four-electrode electrochemical sensing resolves CO from parts-per-billion up to 1000 ppm, for ambient air-quality and traffic-pollution monitoring.

Aethair O₃+NO₂

Gas 0d45

• NO₂ 0-20 ppm res. 15 ppb
• O₃ 0-20 ppm res. 15 ppb

Ozone cartridge. Four-electrode electrochemical sensing measures oxidizing gases (ozone plus nitrogen dioxide) and reports one combined O₃+NO₂ value (shown under both parameters), for ambient air-quality monitoring.

Aethair SO₂

Gas 0d55

• SO₂ 0-100 ppm res. 5 ppb

Sulfur dioxide cartridge. Four-electrode electrochemical sensing resolves SO₂ from parts-per-billion up to 100 ppm, for combustion, industrial-emissions, and ambient air-quality monitoring.

Aethair H₂S

Gas 0d65

• H₂S 0-50 ppm res. 5 ppb

Hydrogen sulfide cartridge. Filtered four-electrode electrochemical sensing resolves H₂S to parts per billion, for wastewater, odor, oil & gas, and safety monitoring.

Aethair HCl

Gas 0d75

• HCl 0-30 ppm res. 0.5 ppm

Hydrogen chloride cartridge. A large-electrolyte electrochemical sensor built for high-humidity, corrosive environments detects HCl for semiconductor etch, exhaust-scrubber, and incineration monitoring.

Aethair HF

Gas 0d85

• HF 0-10 ppm res. 0.05 ppm

Hydrogen fluoride cartridge. Three-electrode electrochemical sensing detects HF at trace levels, for aluminum smelting, glass etching, semiconductor, and refining safety.
