Gill Instruments MaxiMet
Weather Stations
Gill MaxiMet GMX-series compact ultrasonic weather stations. Each model carries a different subset of ultrasonic wind, barometric pressure, temperature, humidity, dew point, and solar radiation, with higher models adding precipitation, GPS, compass, or heat-stress features.
Measures
What the Gill Instruments MaxiMet Measures
7 parameters, each linked to its page: the sensors, units, and standards behind it.
Connects via Thiamis
Models
Gill Instruments MaxiMet Models
16 models, each with what it measures and the ranges its datasheet gives.
| Model | Description | Measures & specs |
|---|---|---|
MaxiMet-GMX100 | Compact PTU (pressure, temperature, humidity) unit: barometric pressure, air temperature, relative humidity, and derived dew point; no wind. Discontinued by Gill; retained for installed-base support. | |
MaxiMet-GMX200 | Ultrasonic wind speed and direction only, with electronic compass and optional GPS. | |
|
MaxiMet-GMX240 | Ultrasonic wind speed and direction with an integrated optical rain sensor and optional GPS; no PTU. | |
|
MaxiMet-GMX260 | MaxiMet Marine: ultrasonic wind speed and direction only, in an IP68 housing with 6-axis compass and optional GPS. | |
MaxiMet-GMX300 | Pressure, temperature, humidity, and derived dew point (PTU); no wind or solar. | |
MaxiMet-GMX301 | GMX300 PTU set plus solar radiation; no wind. | |
MaxiMet-GMX400 | Pressure, temperature, humidity, and derived dew point with an integrated optical rain sensor; no wind. (Gill redefined the GMX400; earlier units were a wind/GPS station.) | |
MaxiMet-GMX500 | Ultrasonic wind plus PTU and derived dew point, with electronic compass and optional GPS and heating. | |
|
MaxiMet-GMX501 | GMX500 wind + PTU set plus solar radiation. | |
MaxiMet-GMX531 | Wind, PTU, derived dew point, and solar radiation with a remote tipping-bucket rain gauge input. Superseded by the GMX551. | |
MaxiMet-GMX550 | Ultrasonic wind plus PTU and derived dew point with a remote tipping-bucket rain gauge connector; optional GPS and heating. | |
|
MaxiMet-GMX551 | Wind, PTU, derived dew point, and solar radiation with a remote tipping-bucket rain gauge connector. | |
|
MaxiMet-GMX552 | Ultrasonic wind plus PTU and derived dew point with on-board heat-stress measurement (black-globe temperature and WBGT). | |
|
MaxiMet-GMX560 | MaxiMet Marine: ultrasonic wind plus PTU and derived dew point in an IP68 housing with 6-axis compass; optional GPS and heating. | |
|
MaxiMet-GMX600 | Ultrasonic wind plus PTU and derived dew point with an integrated optical rain sensor and electronic compass; optional GPS and heating. | |
|
MaxiMet-GMX603 | Ultrasonic wind plus PTU and derived dew point with an improved integrated optical present-weather rain sensor; optional GPS and heating. |
Solutions
Where the Gill Instruments MaxiMet Is Used
Solutions whose recommended configuration uses this instrument or whose standards it is built to, followed by solutions whose core panel it partly measures.
Weather Stations & Meteorology
Professional multi-parameter weather monitoring
On the platform
What the Gill Instruments MaxiMet Gets From Aethair
Connected through Thiamis, its readings arrive in the same Environet account as Aethair's own monitors.
Live data and alerts
Environet shows the instrument live and alerts the people you choose by email, SMS, and webhook, at the thresholds you set. Noesis sets up a dashboard, a report, or an alert from a plain-text request.
Compliance reports
Aethair Reports produces scheduled or on-demand reports from the instrument's readings, as a PDF or secure link. Templates cover Aethair Blue, WELL v2, cabin air (ISO 23875), and the CMS-2567 healthcare codebook (ASHRAE 170), or you can report against custom limits such as OSHA PELs, NAAQS, EPA guidance, or your own program limits.
Dashboards and the app
Environet dashboards and the Aethair App show the instrument's readings just like any Aethair device. The occupant-facing Aethair Dashboards status display is built around Aethair IAQ and Aethair PRO.
Similar
Other Weather Stations
Airmar
Weather Stations
Airmar WeatherStation instruments (compact, maintenance-free ultrasonic multisensors with no moving…
Davis
Weather Stations
Davis Instruments weather stations. The Vantage Pro2 and Vantage Vue are modern integrated stations…
Lufft
Weather Stations
Lufft WS-series compact all-in-one weather sensors (UMB over RS485). One maintenance-free housing…
R.M. Young
Weather Stations
R.M. Young ResponseONE weather instruments, with solid-state ultrasonic wind sensing and no moving…
Questions
Gill Instruments MaxiMet FAQ
How does the integration read a MaxiMet?
Polled ASCII over RS232/RS422/RS485. The driver puts the unit into POLL message mode, reads back the configured REPORT field order, then polls with ?Q each interval and maps every named field to its measurement. Because the report order is read from the device, one driver serves every GMX model.
Is dew point measured or derived?
Derived. The MaxiMet computes dew point on-board from its temperature, humidity, and pressure sensors and emits it as a DEWPOINT field in the data string, which the integration records directly. Models without the PTU sensor block (GMX200, GMX240, GMX260) therefore report no dew point.
Does the same driver work across the land and marine (Marine GMX260/GMX560) models?
Yes. The driver queries the unit for its identity (%% info) and reads back the GMX model number. All MaxiMet models, land and marine, share the same ASCII/SDI-12/NMEA/MODBUS command set, so no per-model configuration is needed.
Sources: gillinstruments.com · gillinstruments.com
