Sensors · Weather Stations
Lufft Weather Stations
Lufft WS-series compact all-in-one weather sensors (UMB over RS485). One maintenance-free housing combines a model-dependent subset of air temperature, humidity, barometric pressure, ultrasonic wind, radar or rain-gauge precipitation, and global radiation; the WS800 adds lightning detection.
Measures
What Lufft Weather Stations Measure
11 parameters, each linked to its page: the sensors, units, and standards behind it.
Connects via Thiamis
Models
Lufft Weather Stations Models
20 models, each with what it measures and the ranges its datasheet gives.
| Model | Description | Measures & specs |
|---|---|---|
WS100 | Radar-only precipitation sensor (24 GHz Doppler): precipitation quantity, type, and intensity. No thermo-hygrometer. The rain-focused member of the WS family. | |
WS200 | Ultrasonic wind speed and direction with an integrated electronic compass; no temperature, humidity, or pressure. | |
WS300 | Thermo-hygrometer-barometer: air temperature, relative humidity, and barometric pressure (dew point and wet bulb calculated). | |
|
WS301 | WS300 (temperature, humidity, pressure) plus global radiation from a built-in pyranometer. | |
|
WS302 | WS300 plus global radiation; shares the WS301 measurement set. | |
WS303 | WS300 plus global radiation; shares the WS301 measurement set. Discontinued, still field-supported. | |
|
WS304 | WS300 plus global radiation; shares the WS301 measurement set. Discontinued, still field-supported. | |
|
WS310 | Compact WS300 plus global radiation; shares the WS301 measurement set. | |
WS400 | Temperature, humidity, and pressure plus radar precipitation (24 GHz Doppler); no wind. | |
WS401 | Temperature, humidity, and pressure plus rain-gauge precipitation (unheated tipping bucket) for low-power use; no wind. | |
WS500 | Temperature, humidity, and pressure plus ultrasonic wind (speed, direction, compass); adds wind chill. | |
|
WS501 | WS500 (T/RH/P + ultrasonic wind) plus global radiation. | |
|
WS502 | WS500 plus global radiation; shares the WS501 measurement set. | |
WS503 | WS500 plus global radiation; shares the WS501 measurement set. Discontinued, still field-supported. | |
|
WS504 | WS500 plus global radiation; shares the WS501 measurement set. Discontinued, still field-supported. | |
WS510 | Compact WS500 plus global radiation; shares the WS501 measurement set. | |
WS600 | Full compact station: temperature, humidity, pressure, ultrasonic wind, and radar precipitation. | |
|
WS601 | WS600 layout with rain-gauge (not radar) precipitation for low-power use. | |
|
WS700 | All-in-one: temperature, humidity, pressure, ultrasonic wind, radar precipitation, and global radiation. | |
WS800 | WS700 parameters plus lightning detection (lightning is reported by the device but not currently ingested by the integration). |
Solutions
Where Lufft Weather Stations Are Used
Solutions whose recommended configuration uses this instrument or whose standards it is built to, followed by solutions whose core panel it partly measures.
Weather Stations & Meteorology
Professional multi-parameter weather monitoring
On the platform
What Lufft Weather Stations Get From Aethair
Connected through Thiamis, its readings arrive in the same Environet account as Aethair's own monitors.
Live data and alerts
Environet shows the instrument live and alerts the people you choose by email, SMS, and webhook, at the thresholds you set. Noesis sets up a dashboard, a report, or an alert from a plain-text request.
Compliance reports
Aethair Reports produces scheduled or on-demand reports from the instrument's readings, as a PDF or secure link. Templates cover Aethair Blue, WELL v2, cabin air (ISO 23875), and the CMS-2567 healthcare codebook (ASHRAE 170), or you can report against custom limits such as OSHA PELs, NAAQS, EPA guidance, or your own program limits.
Dashboards and the app
Environet dashboards and the Aethair App show the instrument's readings just like any Aethair device. The occupant-facing Aethair Dashboards status display is built around Aethair IAQ and Aethair PRO.
Similar
Other Weather Stations
Airmar
Weather Stations
Airmar WeatherStation instruments (compact, maintenance-free ultrasonic multisensors with no moving…
Davis
Weather Stations
Davis Instruments weather stations. The Vantage Pro2 and Vantage Vue are modern integrated stations…
Gill Instruments
Weather Stations
Gill MaxiMet GMX-series compact ultrasonic weather stations. Each model carries a different subset…
R.M. Young
Weather Stations
R.M. Young ResponseONE weather instruments, with solid-state ultrasonic wind sensing and no moving…
Questions
Lufft Weather Stations FAQ
How does the Thiamis integration read a Lufft WS sensor?
Over RS485 using Lufft's UMB binary protocol. The driver auto-detects the connected model from its device-ID string, queries the device's available channel list, then polls those channels each interval, so any WS-family model works without per-model configuration.
How do the WS models differ?
They share one maintenance-free housing but differ by sensor fit. WS200 is wind-only (ultrasonic plus electronic compass); WS100 is precipitation-only (radar). WS300 measures temperature, humidity, and pressure; WS400 adds radar precipitation, WS500 adds ultrasonic wind, WS600 adds both; WS700 adds global radiation and WS800 adds lightning. The x01–x10 variants (e.g. WS301, WS501) add a global-radiation pyranometer to the base model.
Radar or rain gauge for precipitation?
Most precipitation models (WS100, WS400, WS600, WS700, WS800) use a 24 GHz Doppler radar that derives quantity, type, and intensity by correlating drop size and speed. WS401 and WS601 instead use an unheated tipping-bucket rain gauge, recommended for low-power installations. Radar precipitation models are subject to country-specific radio approvals.
Is wet-bulb temperature reported?
Wet-bulb temperature is a supported UMB channel (114/119) that every temperature/humidity/pressure model calculates, and it is listed here as a device capability. The current Thiamis firmware does not poll it by default, but it can be added to the request list on demand without any hardware change.
Is the WS800's lightning data available?
The WS800 detects lightning by analyzing the radio emissions of strikes and reports a strike count over UMB. The current Thiamis driver does not ingest the lightning channel, so it is noted on the WS800 but is not among the delivered parameters.
What does the electronic compass do?
Wind models carry an electronic compass used to verify the housing's north–south alignment and to output a compass-corrected wind direction; it is not reported as a separate measurement.
