TSI DustTrak
Particulate & Dust Monitors
TSI DustTrak real-time light-scattering laser photometers for aerosol/dust mass-concentration monitoring. DustTrak II reports one user-selected size fraction; DustTrak DRX reports PM1/PM2.5/PM4/PM10/Total simultaneously; Environmental models (8540/8543) add a weatherproof enclosure for outdoor/fence-line use, and the M variants add MCERTS certification.
Measures
What the TSI DustTrak Measures
5 parameters, each linked to its page: the sensors, units, and standards behind it.
Connects via Thiamis
Models
TSI DustTrak Models
11 models, each with what it measures and the ranges its datasheet gives.
| Model | Description | Measures & specs |
|---|---|---|
DustTrak 8530 | DustTrak II desktop laser photometer with internal pump; one user-selected size fraction (PM1/PM2.5/Respirable/PM10) reported as mass concentration. | Range: 0.001–400 mg/m³Resolution: 0.001 mg/m³ (or 0.1% of reading) |
|
DustTrak 8530EP | DustTrak II desktop with low-power external pump for continuous 24/7 unattended outdoor monitoring; one user-selected size fraction. | Range: 0.001–400 mg/m³Resolution: 0.001 mg/m³ (or 0.1% of reading) |
|
DustTrak 8532 | DustTrak II handheld laser photometer for walk-through surveys; one user-selected size fraction, real time. | Range: 0.001–150 mg/m³Resolution: 0.001 mg/m³ (or 0.1% of reading) |
DustTrak 8540 | DustTrak Environmental single-fraction monitor in a weatherproof enclosure for outdoor/fence-line use. | Range: 0.001–400 mg/m³Resolution: 0.001 mg/m³ (or 0.1% of reading) |
|
DustTrak 8533 | DustTrak DRX desktop; PM1/PM2.5/PM4/PM10/Total simultaneously from one sample. | Range: 0.001–150 mg/m³Resolution: 0.001 mg/m³ (or 0.1% of reading)Method: Light-scattering laser photometer (with gravimetric reference sampling) datasheet |
|
DustTrak 8533EP | DustTrak DRX desktop with external pump for extended long-term sampling; simultaneous PM1-Total. | Range: 0.001–150 mg/m³Resolution: 0.001 mg/m³ (or 0.1% of reading)Method: Light-scattering laser photometer (with gravimetric reference sampling) datasheet |
|
DustTrak 8534 | DustTrak DRX handheld; simultaneous PM1/PM2.5/PM4/PM10/Total. | Range: 0.001–150 mg/m³Resolution: 0.001 mg/m³ (or 0.1% of reading)Method: Light-scattering laser photometer (with gravimetric reference sampling) datasheet |
|
DustTrak 8543 | DustTrak Environmental DRX; simultaneous PM1-Total in a weatherproof enclosure. | Range: 0.001–150 mg/m³Resolution: 0.001 mg/m³ (or 0.1% of reading) |
|
DustTrak 8540M | DustTrak Environmental single-fraction, MCERTS-certified for PM2.5; weatherproof enclosure with built-in auto-zero. | Range: 0.001–400 mg/m³Resolution: 0.001 mg/m³ (or 0.1% of reading) |
|
DustTrak 8542M | DustTrak Environmental single-fraction, MCERTS-certified for PM10; weatherproof enclosure with built-in auto-zero. | Range: 0.001–400 mg/m³Resolution: 0.001 mg/m³ (or 0.1% of reading) |
|
DustTrak 8543M | DustTrak Environmental DRX, MCERTS-certified for both PM2.5 and PM10; simultaneous PM1/PM2.5/PM4/PM10/Total for regulatory monitoring. | Range: 0.001–150 mg/m³Resolution: 0.001 mg/m³ (or 0.1% of reading) |
Standards
Standards for What It Measures
Standards that set limits on the parameters it reports.
Solutions
Where the TSI DustTrak Is Used
Solutions whose recommended configuration uses this instrument or whose standards it is built to, followed by solutions whose core panel it partly measures.
Perimeter Monitoring
Site boundary dust, silica, and noise compliance
Outdoor Monitoring
Continuous outdoor air quality networks that sit alongside reference monitors
Wildfire Air Monitoring
Smoke plumes, black carbon, and community exposure
Cabin Air Quality
Respirable dust, gases, and blast monitoring
Healthcare Air Monitoring
Clinical air quality, pressurization, and patient safety
Indoor Air Quality
Offices, schools, homes, and public buildings
School Air Monitoring
Classroom CO₂, particulates, and campus IAQ
On the platform
What the TSI DustTrak Gets From Aethair
Connected through Thiamis, its readings arrive in the same Environet account as Aethair's own monitors.
Live data and alerts
Environet shows the instrument live and alerts the people you choose by email, SMS, and webhook, at the thresholds you set. Noesis sets up a dashboard, a report, or an alert from a plain-text request.
Compliance reports
Aethair Reports produces scheduled or on-demand reports from the instrument's readings, as a PDF or secure link. Templates cover Aethair Blue, WELL v2, cabin air (ISO 23875), and the CMS-2567 healthcare codebook (ASHRAE 170), or you can report against custom limits such as OSHA PELs, NAAQS, EPA guidance, or your own program limits.
Dashboards and the app
Environet dashboards and the Aethair App show the instrument's readings just like any Aethair device. The occupant-facing Aethair Dashboards status display is built around Aethair IAQ and Aethair PRO.
Similar
Other Particulate & Dust Monitors
Met One
Particulate & Dust Monitors
Met One (Acoem) real-time particulate monitors. The E-BAM is a portable beta-attenuation mass…
Particles Plus
Particulate & Dust Monitors
Particles Plus 5000-series remote (fixed-install) and 7000-series benchtop instruments are laser…
Thermo Scientific
Particulate & Dust Monitors
This integration covers Thermo Scientific particulate monitors, led by the Partisol iSeries…
Trolex
Particulate & Dust Monitors
Trolex real-time dust and silica monitors for harsh mining and industrial environments: the Air XD…
Article Library
Reading on What These Instruments Measure
Fenceline Air Quality Monitoring: Equipment and Approaches
Compare fenceline air quality monitoring approaches: standalone stations, pelican-case kits, and connected 4G sensor networks.
PM2.5 Exposure Limits & Monitoring: OSHA and NAAQS Standards
What are the OSHA and NAAQS exposure limits for PM2.5? Fine particulate thresholds explained, plus how continuous monitoring keeps workplaces compliant.
Questions
TSI DustTrak FAQ
How does the DustTrak measure dust concentration?
It is a light-scattering laser photometer: the aerosol is drawn through a sheath-air optics chamber and the 90-degree light scattered from a laser diode is converted to a real-time mass concentration in mg/m3. A user-inserted 37 mm gravimetric filter cassette lets you collect a reference sample for custom (gravimetric) calibration.
What is the difference between DustTrak II and DustTrak DRX?
DustTrak II (8530, 8530EP, 8532) is single-channel: it reports one user-selected size fraction, set by the inlet impactor (PM1, PM2.5, Respirable/PM4, or PM10), as a single mass concentration. DustTrak DRX (8533, 8533EP, 8534, and the Environmental 8543/8543M) uses a size-segregated technique to report PM1, PM2.5, PM4 (Respirable), PM10, and Total PM simultaneously from one sample.
What do the EP models add?
EP (8530EP, 8533EP) is a desktop unit with a low-power external pump for continuous, unattended 24/7 monitoring over days to months. The standard desktop (8530, 8533) uses an internal pump suited to shorter work-shift or indoor-air-quality sampling.
What do the M models add, and which fraction is each certified for?
The M models are the MCERTS-certified DustTrak Environmental builds for UK/EU regulatory use, in a weatherproof enclosure with built-in auto-zero. 8540M is certified for PM2.5, 8542M for PM10, and 8543M is the DRX build certified for both PM2.5 and PM10.
Does the integration report a Short-Term Exposure Limit (STEL)?
Yes. The driver supports a 15-minute STEL alarm per size fraction (PM1, PM2.5, PM4, PM10, Total); when a per-fraction setpoint is exceeded it posts the 15-minute average. STEL is an alarm value, not a separately measured parameter.
How does the Thiamis integration talk to the instrument?
Over RS-232 serial at 9600 baud, 8-N-1. On connection the driver auto-detects the model and polls the instrument each interval; the model determines whether one mass value (single-fraction) or five (DRX) are ingested.
