Water Pressure

Water pressure, in this context, is the hydrostatic pressure exerted by a column of water above a submerged sensor, reported in units such as centimeters of water (cmH₂O) or pounds per square inch (psi). It is distinct from barometric (atmospheric) pressure: it is the pressure the water itself adds, and it rises in direct proportion to the depth of water above the sensor. Because that relationship is linear and well understood, water pressure is the quantity a submersible transducer actually senses, and water level or depth is derived from it. A reading can be absolute, including the weight of the atmosphere pressing on the surface, or gauge (vented), where the atmospheric component is canceled at the sensor so that only the water column remains.

Because it is what submersible level sensors measure directly, water pressure underpins groundwater, surface-water, and level monitoring wherever a pressure transducer is deployed.

Water pressure is the raw signal behind depth and level, so its quality sets the quality of every derived level and flow value. In groundwater monitoring, a downhole transducer records the pressure of the water standing above it, from which the depth to the water table (and thus aquifer behavior, recharge, and the impact of pumping) is calculated. In rivers, tanks, and reservoirs the same principle turns a submerged sensor into a continuous stage or fill-height record. Whether a sensor reads absolute or gauge pressure also matters operationally: an absolute sensor must be paired with a barometric reference so the atmospheric part can be removed, or the derived level will drift with the weather.

For hydrologists, groundwater specialists, and site operators, water pressure is therefore the foundational measurement from which level and flow are built.

Water pressure is measured with a submersible pressure transducer logged on a Thiamis gateway for continuous measurement. The sensor sits at a known, fixed depth and its diaphragm responds to the pressure of the water column above it. Vented (gauge) sensors run a tube to the surface so that changing atmospheric pressure is canceled at the diaphragm, leaving only the water column. Non-vented (absolute) sensors are simpler and more rugged but record water plus atmosphere, so a separate barometric sensor is used to compensate the record. Transducers are temperature-compensated and referenced to a known elevation, and they need periodic checks against a manual dip because zero drift is the main long-term limitation.
